4G SFP – Welcome to JNT Networks

2.5G SFP

4Gbps transmission

Applications

Ethernet (100M/ 1G)
ESCON/ FICON
4G Fiber channel
OC-3/12/48 or STM-1/4/16
Multi-rate 100Mbps to 4.25Gbps

Small Form Pluggable (SFP) Transceiver Modules available with:

Dual Fiber Strands SFP Modules
CWDM Dual Fiber Strands SFP Modules

Supports various wavelengths such as 850nm, 1300nm, 1310nm, 1550nm, CWDM , and distances up to 40km
Digital Diagnostic Monitoring (DDM) for optical monitoring capability compliant with SFF-8472 (Internal/ External Calibration)
Supports Normal Operating Temperature 0 to +70 or Industrial Operating Temperature -40 to +85 degree Celsius
Compatible to major equipment vendors (Coding)
2 years warranty with optional extended warranty up to 5 years

Ordering Information

Temperature Option : Standard temperature – 0°C to +70°C; Industrial temperature – -40°C to +85°C

Dual Fiber Strands SFP Modules

CWDM Dual Fiber Strands SFP Modules

Dual Fiber Strands SFP Modules

Standard

Industrial

Standard

Data Rate	Part Number	Type	Wavelength	Distance (km)	TX Power (dBm)	RX Sens. (dBm)	Fiber Budget (dB)
	SFP-OC3M8D	MM	850nm	2	-9 to -3	-24 to -6	12
	SFP-OC3MD	MM	1300nm	2	-20 to -14	-28 to -8	5
100Mb/s	SFP-OC3SD2	SM	1310nm	20	-15 to -8	-29 to -8	14
(FE / STM-1 /	SFP-OC3SD4	SM	1310nm	40	-7 to -2	-32 to -10	25
OC-3)	SFP-OC3SD8	SM	1550nm	80	-5 to 0	-33 to -10	28
	SFP-OC3SD12	SM	1550nm	120	-2 to 3	-34 to -10	32
	SFP-OC3SD16	SM	1550nm	160	1 to 5	-37 to -10	36
————————	————————	————————	————————	————————	————————	————————	————————
	SFP-OC12SD2	SM	1310nm	20	-15 to -8	-28 to -8	13
622 Mb/s	SFP-OC12SD4	SM	1310nm	40	-5 to 0	-28 to -8	23
(STM-4 / OC-	SFP-OC12SD8	SM	1550nm	80	-3 to 2	-28 to -8	25
12)	SFP-OC12SD12	SM	1550nm	120	0 to 5	-31 to -8	31
————————	————————	————————	————————	————————	————————	————————	————————
	SFP-SXD	MM	850nm	0.22	-9 to -3	-17 to 0	5
	SFP-ESXD	MM	1300nm	2	-5 to 0	-20 to 0	15
	SFP-LXD1	SM	1310nm	10	-9 to -3	-20 to -3	11
1.25 Gb/s	SFP-LXD2	SM	1310nm	20	-9 to -3	-20 to -3	11
(Gbe / FC)	SFP-LXD4	SM	1310nm	40	-5 to 0	-24 to -1	19
	SFP-ZXD6	SM	1550nm	60	0 to 5	-26 to -3	26
	SFP-ZXD8	SM	1550nm	80	0 to 5	-26 to -3	26
	SFP-ZXD12	SM	1550nm	120	0 to 5	-31 to -10	31
	SFP-ZXD16	SM	1550nm	160	2 to 6	-34 to -10	36
————————	————————	————————	————————	————————	————————	————————	————————
	SFP-2GSXD	MM	850nm	0.3	-10 to -3	-18 to -3	5
	SFP-2GLXD	SM	1310nm	2	-9 to -3	-18 to -3	9
Multi-rate	SFP-2GLXD1	SM	1310nm	10	-5 to 0	-19 to 0	14
2.125 Gbps/s to	SFP-2GLXD2	SM	1310nm	20	-5 to 0	-19 to 0	14
2.7 Gb/s	SFP-2GLXD4	SM	1310nm	40	-2 to 3	-19 to 0	17
	SFP-2GZXD4	SM	1550nm	40	-2 to 3	-19 to 0	17
	SFP-2GZXD8	SM	1550nm	80	0 to 5	-28 to -6	28
	SFP-2GZXD12	SM	1550nm	120	1 to 6	-30 to -10	31
————————	————————	————————	————————	————————	————————	————————	————————
	SFP-4GSXD	MM	850nm	0.55	-9 to -2.5	-16 to 0	4
Multi-rate	SFP-4GLXD	SM	1310nm	2	-6 to -1	-18 to 0.5	12
100Mb/s to	SFP-4GLXD1	SM	1310nm	10	-6 to -1	-18 to 0.5	12
4.25Gb/s	SFP-4GLXD2	SM	1310nm	20	-6 to -1	-18 to 0.5	12
	SFP-4GLXD4	SM	1310nm	40	-1 to 4	-18 to 0.5	17

Industrial

Data Rate	Part Number	Type	Wavelength	Distance (km)	TX Power (dBm)	RX Sens. (dBm)	Fiber Budget (dB)
	SFP-OC3M8DH	MM	850nm	2	-9 to -3	-24 to -6	12
	SFP-OC3MDH	MM	1310nm	2	-20 to -14	-28 to -8	5
100Mb/s	SFP-OC3SD2H	SM	1310nm	20	-15 to -8	-29 to -8	14
(FE / STM-1 /	SFP-OC3SD4H	SM	1310nm	40	-7 to -2	-32 to -10	25
OC-3)	SFP-OC3SD8H	SM	1550nm	80	-5 to 0	-33 to -10	28
	SFP-OC3SD12H	SM	1550nm	120	-2 to 3	-34 to -10	32
	SFP-OC3SD16H	SM	1550nm	160	1 to 5	-37 to -10	36
————————	————————	————————	————————	————————	————————	————————	————————
	SFP-OC12SD2H	SM	1310nm	20	-15 to -8	-28 to -8	13
622 Mb/s	SFP-OC12SD4H	SM	1310nm	40	-5 to 0	-28 to -8	23
(STM-4 / OC-	SFP-OC12SD8H	SM	1550nm	80	-3 to 2	-28 to -8	25
12)	SFP-OC12SD12H	SM	1550nm	120	0 to 5	-31 to -8	31
————————	————————	————————	————————	————————	————————	————————	————————
	SFP-SXDH	MM	850nm	0.22	-9 to -3	-17 to 0	5
	SFP-ESXDH	MM	1300nm	2	-5 to 0	-20 to 0	15
	SFP-LXD1H	SM	1310nm	10	-9 to -3	-20 to -3	11
1.25 Gb/s	SFP-LXD2H	SM	1310nm	20	-9 to -3	-20 to -3	11
(Gbe / FC)	SFP-LXD4H	SM	1310nm	40	-5 to 0	-24 to -1	19
	SFP-ZXD6H	SM	1550nm	60	0 to 5	-26 to -3	26
	SFP-ZXD8H	SM	1550nm	80	0 to 5	-26 to -3	26
	SFP-ZXD12H	SM	1550nm	120	0 to 5	-31 to -10	31
	SFP-ZXD16H	SM	1550nm	160	2 to 6	-34 to -10	36
————————	————————	————————	————————	————————	————————	————————	————————
	SFP-2GSXDH	MM	850nm	0.3	-10 to -3	-18 to -3	5
	SFP-2GLXDH	SM	1310nm	2	-9 to -3	-18 to -3	9
Multi-rate	SFP-2GLXD1H	SM	1310nm	10	-5 to 0	-19 to 0	14
2.125 Gbps/s to	SFP-2GLXD2H	SM	1310nm	20	-5 to 0	-19 to 0	14
2.7 Gb/s	SFP-2GLXD4H	SM	1310nm	40	-2 to 3	-19 to 0	17
	SFP-2GZXD4H	SM	1550nm	40	-2 to 3	-19 to 0	17
	SFP-2GZXD8H	SM	1550nm	80	0 to 5	-28 to -6	28
	SFP-2GZXD12H	SM	1550nm	120	1 to 6	-30 to -6	31
————————	————————	————————	————————	————————	————————	————————	————————
	SFP-4GSXDH	MM	850nm	0.55	-9 to -2.5	-16 to 0	4
Multi-rate	SFP-4GLXDH	SM	1310nm	2	-6 to -1	-18 to 0.5	12
100Mb/s to	SFP-4GLXD1H	SM	1310nm	10	-6 to -1	-18 to 0.5	12
4.25Gb/s	SFP-4GLXD2H	SM	1310nm	20	-6 to -1	-18 to 0.5	12
	SFP-4GLXD4H	SM	1310nm	40	-1 to 4	-18 to 0.5	17

CWDM Dual Fiber Strands SFP Modules

Standard

Data Rate	Part Number	Type	Wavelength	Distance (km)	TX Power (dBm)	RX Sens. (dBm)	Fiber Budget (dB)
100Mb/s	SFP-OC3SD12C##	SM	1470nm ~ 1610nm	120	-2 to 3	-34 to -10	32
(FE / STM-1 / OC-3)	SFP-OC3SD16C##	SM	1450nm ~ 1610nm	160	0 to 5	-35 to -10	35
————————	————————	————————	————————	————————	————————	————————	————————
1.25 Gb/s	SFP-ZXD4C##	SM	1270nm ~ 1610nm	40	-5 to 0	-24 to -1	19
(Gbe / FC)	SFP-ZXD8C##	SM	1270nm ~ 1610nm	80	0 to 5	-26 to -3	26
	SFP-ZXD12C##	SM	1270nm ~ 1610nm	120	0 to 5	-32 to -10	32
	SFP-ZXD16C##	SM	1470nm ~ 1610nm	160	2 to 6	-34 to -10	36
————————	————————	————————	————————	————————	————————	————————	————————
Multi-rate	SFP-2GZX4CD##	SM	1270nm ~ 1610nm	40	-2 to 3	-19 to 0	17
100Mb/s to 2.488 Gb/s	SFP-2GZX8CD##	SM	1270nm ~ 1610nm	80	0 to 5	-28 to -9	28
	SFP-2GZX12CD##	SM	1470nm ~ 1610nm	120	2 to 6	-30 to -10	32
————————	————————	————————	————————	————————	————————	————————	————————
Multi-rate	SFP-4GZXD4C##	SM	1310nm ~ 1610nm	40	-1 to 4	-18 to 0.5	17

## denotes wavelength range from 1270~1610nm.
27 = 1270nm, 29=1290nm, 31=1310nm, 33=1330nm, 35=1350nm, 37=1370nm, 39=1390nm, 41=1410nm, 43=1430nm, 45=1450nm, 47=1470nm, 49=1490nm, 51=1510nm, 53=1530nm, 55=1550nm,57=1570nm, 59=1590nm, 61=1610nm
