Temperature Option : Standard Temperature – 0°C to +70°C ; Industrial temperature – -5°C to +85°C
| Data Rate | Part Number | Type | Wavelength | Distance (km) | TX Power (dBm) | RX Sens. (dBm) | Fiber Budget (dB) | Datasheet |
|---|---|---|---|---|---|---|---|---|
| 50Gb/s | QSFP-50G-LR1 | SM | 1310nm | 10 | -4.5 to 4.2 | -10.3 to 4.2 | 5.8 |  |
| QSFP-50G-ER4 | SM | 1310nm | 40 | 0.4 to 6.6 | -17.6 to -3.4 | 18 | |
| Data Rate | Part Number | Type | Wavelength | Distance (km) | TX Power (dBm) | RX Sens. (dBm) | Fiber Budget (dB) | Datasheet |
|---|---|---|---|---|---|---|---|---|
| 50Gb/s | QSFP-50G-LR11 | SM | 1271TX 1331RX | 10 | -4.5 to 4.2 | -10.8to 4.2 | 6.3 | |
| QSFP-50G-LR12 | SM | 1331TX 1271RX | 10 | -4.5 to 4.2 | -10.8to 4.2 | 6.3 | |
|
| QSFP-50G-ER41 | SM | 1295TX 1309RX | 40 | 0.4 to 6.6 | -17.6 to -3.4 | 18 | |
|
| QSFP-50G-ER42 | SM | 1309TX 1295RX | 40 | 0.4 to 6.6 | -17.6 to -3.4 | 18 | |
